Manganese Steel Plate

Whether you are in mining, construction or manufacturing, manganese plate is your material of choice for manufacturing critical components. Its unique properties make it ideal for crusher jaws, where it can withstand the relentless grinding of rocks and minerals. In addition, it performs well in hammers and mills, providing the strength needed to break down tough materials without compromising performance.


    Picture Name

    Manganese Steel Plate Description

    Manganese plate’s versatility extends to large excavators where it can be used as cutting edges that require excellent wear resistance. Its rugged nature ensures these edges maintain integrity, reducing downtime and maintenance costs. Additionally, manganese plate is ideal for use as a liner in shot peening equipment, preventing abrasive erosion and extending the life of the equipment.In foundry applications, manganese plate is an integral material for mold cores and walls, providing the necessary resilience to withstand high temperatures and pressures. In addition, its use in screens ensures that your operations run smoothly and minimizes the risk of wear-related failures.Investing in Manganese Plate means investing in reliability and performance. Its ability to withstand extreme conditions and resist wear makes it an ideal choice for any application that demands optimal operation. Choose Manganese Plate for your next project and experience the difference in quality and durability that sets us apart from the competition.

    Product Parameters

    Product Name

    Manganese Steel Plate

    Production Process

    Hot Rolling, Cold Rolling

    Material Standards

    AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc.

    Width

    100mm-3000mm

    Length

    1m-12m, or Customized Size

    Thickness

    0.1mm-400mm

    Delivery Conditions

    Rolling, Annealing, Quenching, Tempered or Standard

    Surface Process

    Ordinary, Wire Drawing, Laminated Film

    Chemical Composition

    Jiuzhou Metal is an austenitic, non-magnetic steel produced to A128 specifications.

    Carbon

    1.05 - 1.2

    Manganese

    11.5 - 14

    Silicon

    1.00 Max

    Phosphorus

    0.07 Max

    Mechanical Properties

    Tensile Strength

    125 ksi

    Yield Strength

    52 ksi

    Elongation in 2”

    45 %

    Scope of Application

    Because of its self hardening properties, manganese steel has been used in the mining industry for many years – cement mixers, rock crushers, crawler treads for tractors, elevator and shovel buckets – as well as in the rail industry (switches and crossings) and other high impact environments.
