First Class GB/T8162 Seamless Steel Pipe

This standard pertains to seamless steel tubes intended for general structural and mechanical applications. The primary steel pipe grades produced include Gr 10, Gr 20, Gr 35, Gr 45, Q345, 15CrMo, and 12Cr1MoV.

Wechat:13256351334
WhatsApp:+8613256351334
E-Mali:admin@sdxyy.cn

product details

Warehouse

Product testing

Customer feedback

equipment

Transport packaging

GB/T8162 Seamless Steel Pipe description

GB/T8162 is a standard for seamless pipes, designed for use in general and mechanical structures. The parts produced from quenching and tempering of GB/T8162 seamless steel pipes exhibit excellent comprehensive mechanical properties and are extensively utilized in various critical structural components, particularly connecting rods, bolts, gears, and shafts operating under alternating loads. However, the surface hardness is relatively low and lacks wear resistance. To enhance the surface hardness of the parts, quenching and tempering, as well as surface quenching, can be employed.

Product Parameters

Product Name	GB/T8162 Seamless Steel Pipe
Standard	EN/DIN/JIS/ASTM/BS/ASME/AISI etc.
Outer Diameter	Seamless: 1/4"-36"	Welding: 21.3mm-3620mm
	Round Tube: 1/2"-10"	Square Tube/Rectangular Tube: 15x15mm-400x600mm
Wall Thickness	Seamless: 1.25mm-50mm	Welding: 1.65mm-65mm
Length	3-12 meters, Support customization
Surface Process	Bright, Polished, Black
Other Services	Machining(cnc), Centerless Grinding(cg), Heat Treatment, Annealing, Pickling, Polishing, Rolling, Forging, Cutting, Bending, Small Machining, etc.
Scope of Application	Seamless steel tubes for fabricating pipes, vessels, equipment, fittings, and mechanical structures.

Chemical Composition

Grade	C	Si	Mn	P, S	Cu	Ni	Mo	Cr
10	0.07～0.14	0.17～0.37	0.35～0.65	≤ 0.035	≤0.25	≤0.25	/	≤ 0.15
20	0.17～0.24	0.17～0.37	0.35～0.65	≤ 0.035	≤0.25	≤0.25	/	≤0.25
35	0.32～0.40	0.17～0.37	0.50～0.80	≤ 0.035	≤0.25	≤0.25	/	≤0.25
45	0.42～0.50	0.17～0.37	0.50～0.80	≤ 0.035	≤0.25	≤0.25	/	≤0.25
16Mn	0.12～0.20	0.20～0.55	1.20～1.60	≤ 0.035	≤0.25	≤0.25	/	≤0.25
12CrMo	0.08～0.15	0.17～0.37	0.40～0.70	≤ 0.035	≤0.25	≤0.30	0.40～0.55	0.40～0.70
15CrMo	0.12～0.18	0.17～0.37	0.40～0.70	≤ 0.035	≤0.25	≤0.30	0.40～0.55	0.80～1.10
12Cr1MoV	0.08～0.15	0.17～0.37	0.40～0.70	≤ 0.035	≤0.25	≤0.30	0.25～0.35	0.90～1.20

Mechanical Properties

Grade	Tensile Strength(MPa)	Yield Strength(MPa)	Elongation(%)
10	≥ 335	≥ 205	≥ 24
20	≥ 390	≥ 245	≥ 20
35	≥ 510	≥ 305	≥ 17
45	≥ 590	≥ 335	≥ 14
16Mn	≥ 490	≥ 325	≥ 21
12CrMo	≥ 410	≥ 265	≥ 24
15CrMo	≥ 440	≥ 295	≥ 22
12Cr1MoV	≥ 490	≥ 245	≥ 22
