DC01/DC02/DC03/DC04 Cold Rolled Steel Plate

DC01, DC02, DC03 and DC04 are classified according to their maximum allowable yield strength, ensuring you have the right material for your specific needs. Each grade is engineered to provide optimal formability and weldability, making it ideal for industries such as automotive, construction and manufacturing. Whether you are producing complex components or rugged structures, our cold rolled steel grades provide the strength and durability needed to stand the test of time.


    Picture Name

    DC01/DC02/DC03/DC04 Cold Rolled Steel Plate

    DC01 is known for its excellent surface quality and is often used in applications where aesthetics are critical. DC02 combines strength and ductility for a variety of forming processes. DC03 is designed for applications that require higher strength without sacrificing formability, while DC04 is the preferred choice for projects that require superior mechanical properties.Our cold rolled steel is produced using advanced manufacturing techniques, ensuring consistency and precision in every batch. We are committed to quality and sustainability, sourcing materials responsibly and adhering to rigorous testing protocols to ensure our products meet or exceed industry standards.Choose our DC01, DC02, DC03 and DC04 cold rolled steel grades for your next project and experience the perfect combination of strength, versatility and reliability. Boost your production capabilities with our high-quality steel solutions designed to meet the changing needs of modern industry.

    Product Parameters

    Product Name

    DC01/DC02/DC03/DC04 Cold Rolled Steel Plate

    Production Process

    Hot Rolling, Cold Rolling

    Material Standards

    AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc.

    Width

    100mm-3000mm

    Length

    1m-12m, or Customized Size

    Thickness

    0.1mm-400mm

    Delivery Conditions

    Rolling, Annealing, Quenching, Tempered or Standard

    Surface Process

    Ordinary, Wire Drawing, Laminated Film

    Chemical Composition

    C

     max. 0,08 %

    Mn

     max. 0,40 %

    P

     max. 0,03 %

    S

     max. 0,03 %

    Mechanical Properties

    Steel Grade

    Yield Strength (MPa) min

    Tensile Strength (MPa) min

    Elongation % min

    Old Description

    DC01

    ≤280

    270-410

    28

    St 12-03

    DC03

    ≤240

    270-370

    34

    St 13-03

    DC04

    ≤210

    270-350

    38

    St 14-03

    DC05

    ≤180

    270-330

    40

    St 15-03

    DC06

    ≤170

    270-330

    41

    -

    DC07

    ≤150

    250-310

    44

    -

    Scope of Application

    DC01 can be used for simple forming work, for example Bending, embossing, beading and pulling.
    DC03 is suitable for forming requirements like Deep drawing and difficult profiles suitable.
    DC04 is suitable for high deformation requirements.
    DC05 is a thermal forming grade, it is suitable for higher forming requirements.
    DC06 is a grade for special deep drawing, suitable for the higher deformation requirements.
    DC07, this superior deep drawing quality is suitable for highest deformation requirements.
