DC01/DC02/DC03/DC04 Cold Rolled Steel Plate
DC01 is known for its excellent surface quality and is often used in applications where aesthetics are critical. DC02 combines strength and ductility for a variety of forming processes. DC03 is designed for applications that require higher strength without sacrificing formability, while DC04 is the preferred choice for projects that require superior mechanical properties.Our cold rolled steel is produced using advanced manufacturing techniques, ensuring consistency and precision in every batch. We are committed to quality and sustainability, sourcing materials responsibly and adhering to rigorous testing protocols to ensure our products meet or exceed industry standards.Choose our DC01, DC02, DC03 and DC04 cold rolled steel grades for your next project and experience the perfect combination of strength, versatility and reliability. Boost your production capabilities with our high-quality steel solutions designed to meet the changing needs of modern industry.
Product Parameters
Product Name |
DC01/DC02/DC03/DC04 Cold Rolled Steel Plate |
Production Process |
Hot Rolling, Cold Rolling |
Material Standards |
AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc. |
Width |
100mm-3000mm |
Length |
1m-12m, or Customized Size |
Thickness |
0.1mm-400mm |
Delivery Conditions |
Rolling, Annealing, Quenching, Tempered or Standard |
Surface Process |
Ordinary, Wire Drawing, Laminated Film |
Chemical Composition
C |
max. 0,08 % |
Mn |
max. 0,40 % |
P |
max. 0,03 % |
S |
max. 0,03 % |
Mechanical Properties
Steel Grade |
Yield Strength (MPa) min |
Tensile Strength (MPa) min |
Elongation % min |
Old Description |
DC01 |
≤280 |
270-410 |
28 |
St 12-03 |
DC03 |
≤240 |
270-370 |
34 |
St 13-03 |
DC04 |
≤210 |
270-350 |
38 |
St 14-03 |
DC05 |
≤180 |
270-330 |
40 |
St 15-03 |
DC06 |
≤170 |
270-330 |
41 |
- |
DC07 |
≤150 |
250-310 |
44 |
- |
Scope of Application
DC01 can be used for simple forming work, for example Bending, embossing, beading and pulling.
DC03 is suitable for forming requirements like Deep drawing and difficult profiles suitable.
DC04 is suitable for high deformation requirements.
DC05 is a thermal forming grade, it is suitable for higher forming requirements.
DC06 is a grade for special deep drawing, suitable for the higher deformation requirements.
DC07, this superior deep drawing quality is suitable for highest deformation requirements.
