A573/A573M Carbon Steel Plate

Introducing our premium ASTM A573/A573M steel plates designed to meet the rigorous demands of structural applications. Available in grades 58, 65 and 70, these high-quality carbon manganese silicon steel plates are designed to meet a wide range of tensile strength requirements, providing superior performance.


    Picture Name

    A573/A573M Carbon Steel Plate Description

    Our ASTM A573/A573M steel plates are specially formulated to improve notch toughness at room temperature, making them ideal for projects that require exceptional durability and resilience. Whether you are constructing bridges, buildings, or other critical infrastructure, these plates provide the reliability and strength needed to withstand the challenges of everyday use.Our steel plates have a unique composition that ensures excellent weldability and formability for seamless integration into a variety of structural designs. Focused on quality and performance, our ASTM A573/A573M steel plates undergo rigorous testing and quality control measures to ensure they meet or exceed industry standards.These steel plates have the versatility to be used in a variety of applications including, but not limited to, construction, manufacturing, and heavy machinery. Their rugged nature makes them an excellent choice for environments that require high strength and toughness, ensuring your project will stand the test of time.

    Product Parameters

    Product Name

    A573/A573M Carbon Steel Plate

    Production Process

    Hot Rolling, Cold Rolling

    Material Standards

    AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc.

    Width

    100mm-3000mm

    Length

    1m-12m, or Customized Size

    Thickness

    0.1mm-400mm

    Delivery Conditions

    Rolling, Annealing, Quenching, Tempered or Standard

    Surface Process

    Ordinary, Wire Drawing, Laminated Film

    Chemical Composition

    A573

    C max

    Mn

    P max

    S max

    Si

    Grade 58

    0.23

    0.60-0.90

    0.035

    0.04

    0.10-0.35

    Grade 65

    0.24-0.26

    0.85-1.20

    0.035

    0.04

    0.15-0.40

    Grade 70

    0.27-0.28

    0.85-1.20

    0.035

    0.04

    0.15-0.40

    Mechanical Properties

    A573

    Tensile Strength

    Yield Strength

    Elongation %

    Grade 58

    58

    400-490 Mpa

    220 Mpa

    21

    Grade 65

    65

    450-530 Mpa

    240 Mpa

    20

    Grade 70

    70

    485-620 Mpa

    290 Mpa

    28

    Physical Performance

    Physical Performance

    Metric

    Imperial

    Density

    7.85 g/cm3

    0.282 lb/in³

    Scope of Application

    ASTM A573 grade steel plate for welded bridge structures.
