A514 Carbon Steel Coil Description
Product Parameters
Product Name |
A514 Carbon Steel Coil |
Production Process |
Hot Rolling, Cold Rolling |
Material Standards |
AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc. |
Width |
45mm-2200mm |
Length |
Custom Size |
Thickness |
Hot Rolling: 2.75mm-100mm |
Delivery Conditions |
Rolling, Annealing, Quenching, Tempered or Standard |
Surface Process |
Ordinary, Wire Drawing, Laminated Film |
Chemical Composition
A514 |
C |
Mn |
P |
S |
Ni |
Cr |
Mo |
Grade A |
0.15-0.21 |
0.80-1.10 |
0.035 |
0.4-0.8 |
- |
0.5-0.8 |
0.18-0.28 |
Grade B |
0.12-0.21 |
0.70-1.0 |
0.035 |
0.20-0.35 |
- |
0.4-0.65 |
0.15-0.25 |
Grade C |
0.1-0.2 |
1.10-1.5 |
0.035 |
0.15-0.30 |
- |
- |
0.15-0.30 |
Grade E |
0.12-0.20 |
0.4-0.7 |
0.035 |
0.2-0.4 |
- |
1.40-2.0 |
0.4-0.6 |
Grade F |
0.1-0.2 |
0.60-1.0 |
0.035 |
0.15-0.35 |
0.70-1.0 |
0.4-0.65 |
0.4-0.6 |
Grade H |
0.12-0.21 |
0.95-1.3 |
0.035 |
0.20-0.35 |
0.3-0.7 |
0.4-0.65 |
0.2-0.3 |
Grade J |
0.12-0.21 |
0.45-0.7 |
0.035 |
0.20-0.35 |
- |
- |
0.50-0.65 |
Mechanical Properties
A514 |
Thickness mm |
Yield Strength Min Mpa |
Tensile Strength Mpa |
Elongation Rate Min % |
|
20 |
690 |
760-895 |
18 |
|
20-65 |
690 |
760-895 |
18 |
|
65-150 |
620 |
690-895 |
18 |
Physical Performance
Physical Performance |
Metric |
Imperial |
Density |
7.85 g/cm3 |
0.284 lb/in³ |
Scope of Application
ASTM A514 steel plate is used where welding, processing, and ultra-high-strength steel are required to reduce weight or meet high-strength requirements. ASTM A514 steel plate is a commonly used structural steel in building construction, used in cranes or other large machinery that bears high loads.
